Product Features
Torque range: 45–3,800 Nm.
Features a modular design, allowing different tool configurations to be assembled according to specific working conditions and application requirements.
Equipped with a high-performance reversible pneumatic motor and precision planetary gearing to deliver continuous, impact-free torque output. Torque accuracy: <5%.
Features ultra-low-pressure starting capability and can begin operating with an inlet air pressure of more than 1 bar.
Precision multi-stage planetary gear system provides a compact, lightweight, and short-body design, making the wrench suitable for confined and restricted working spaces.
Equipped with an advanced intelligent digital air supply controller, allowing the required torque value to be set directly without using a pressure-to-torque reference chart.
When ordered together with the 001-A-0112 Intelligent Digital Torque Controller, complete system calibration can be provided to minimize errors caused by air pressure variations and improve overall system accuracy.
Air supply requirement: <560 L/min @ 7.2 bar.
A protective tool case is included as standard.
An impact-free pneumatic torque wrench without the digital torque controller is also available.
